SoundQubed S4-100 S Series 4 Channel Amplifier, 700w

Model: S4-100   Sold as: Each

High-Efficiency Multi-Channel Power

The S4-100 is a high-efficiency Class D multi-channel amplifier that delivers powerful, balanced sound across the entire frequency range. Designed to enhance both low-end bass and mid/high frequencies, the S4-100 is the perfect amplifier for those looking to take their car audio to the next level.

With 175 Watts per channel at 2 Ohms on four channels, and 100 Watts per channel at 4 Ohms, the S4-100 provides ample power for your speakers. For systems requiring more power, your customer can run it in stereo at 375 Watts at 4 Ohms on two channels, making it ideal for driving speakers in car audio competitions or sound quality systems.

When looking to maximize sound quality and volume, pairing the S4-100 with SoundQubed mid-range speakers and tweeters is an excellent choice. The amplifier’s high-pass crossovers allow for precise tone control, ensuring that only the frequencies suitable for your customers tweeters and midrange speakers are directed to them. This prevents speaker damage from unwanted low-end bass tones.

Additionally, the bandpass filter on the S4-100 lets you eliminate unwanted high and low frequencies, giving your customer greater control over the sound output. This is ideal for creating a separation between your mid-range speakers and tweeters. A low-pass filter is also included, allowing your customer to adjust the amount of low frequency sent to your customers speakers.

The S4-100 features 4-gauge set screw power terminals for secure cable connections and 10-gauge set screw speaker terminals to ensure optimal performance.

If your customer is looking for a separate subwoofer amplifier, pairing the S4-100 with the S1-850 or Q1-1200.2 will create the perfect synergy between sound quality and bass.

Specifications:
Channels: 4 channels
Working Voltage: 12 - 15.8 volts
Maximum Amperage: 75 Amps
Power @ 4 Ohm Stereo: 100 Watts x 4 channels
Power @ 2 Ohm Stereo: 175 Watts x 4 channels
Power @ 4 Ohm Mono: 370 Watts x 2 channels
Frequency Response: 10 Hz - 40 kHz
S/N Ratio: Greater than 80
Damping Factor: Greater than 100
Input Sensitivity: 8 V - 0.2 V
Subsonic Filter: 20 Hz - 5 kHz
Low-Pass Filter: 50 Hz - 5 kHz
Dimensions (L x W x H): 7.87" x 7.75" x 2.24"
