With NexD™ technology, XDM amplifiers achieve total amplifier efficiencies exceeding 80%. This results in reduced energy use, making them much kinder to your electrical system.
MULTIPLE CONFIGURATIONS TO FIT NEARLY ANYWHERE
EXCLUSIVE INPUT FILTER FOR AMAZING AUDIO ON LAND OR SEA
EFFICIENT DESIGN FOR HIGH OUTPUT USES LESS ENERGY
FULL SUITE OF STUDIO-GRADE SIGNAL PROCESSING ON BOARD
UNIQUE DESIGN ADJUSTS OPERATION TO AVOID THERMAL EVENTS
3-YEAR WARRANT
| Warranty | 3 years |
|---|---|
| Channels | Monoblock/2/3/4/5/6/8 |
| Physical dimensions (Height) | 2.05" (52 mm) |
| Physical dimensions (Width) | Monoblock (300 W)/2-Channel: 6.85" (174 mm) Monoblock (600 W)/3/4-Channel: 8.52" (216 mm) 5 (700 W)/ 6-Channel: 10.23" (260 mm) Monoblock (1000 W)/5 (1000 W)/8-Channel: 14.73" (374 mm) |
| Physical dimensions (Depth) | 7.09" (180 mm) |
| Weight |
Monoblock (300 W): 3.8 lbs (1.72 kg) |
| Operating voltage | 11-14.5 VDC (12 V Models) |
Audio |
|
| Amplifier class | Class D |
|---|---|
| Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD) |
Monoblock (300 W): 200 W x 1 |
| Rated continuous (RMS) power (14.4 V input @ 2 Ohm < 1% THD) |
Monoblock (300 W): 300 W x 1 |
| Rated continuous (RMS) power (12.5 V input @ 4 Ohm < 1% THD) |
Monoblock (300 W): 160 W x 1 |
| Rated continuous (RMS) power (12.5 V input @ 2 Ohm < 1% THD) |
Monoblock (300 W): 270 W x 1 |
| Rated continuous (RMS) power (28.8 V input @ 4 Ohm < 1% THD) |
6-Channel (24 V): 75 W x 6/200 W x 3 (Bridged) |
| Rated continuous (RMS) power (28.8 V input @ 2 Ohm < 1% THD) |
6-Channel (24 V): 100 W x 6 |
| Rated continuous (RMS) power (25 V input @ 4 Ohm < 1% THD) |
6-Channel (24 V): 60 W x 6/180 W x 3 (Bridged) |
| Rated continuous (RMS) power (25 V input @ 2 Ohm < 1% THD) |
6-Channel (24 V): 90 W x 6 |
| Signal-to-noise ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | Monoblock (300 W): > 100 dB Monoblock (600 W): > 87 dB Monoblock (1000 W): > 83 dB 2/4/6-Channel: > 104 dB |
| Signal-to-noise ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs - Main channels | 3/5-Channel: > 104 dB |
| Signal-to-noise ratio, referred to highest rated power (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs - Subwoofer channel | 3/5-Channel: > 103 dB |
| Signal-to-noise ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs | Monoblock (300 W): > 80 dB Monoblock (600 W): > 67 dB Monoblock (1000 W): > 53 dB 2/4/6-Channel: > 84 dB |
| Signal-to-noise ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs - Main channels | 3/5-Channel: > 84 dB |
| Signal-to-noise ratio, referred to 1 W (A-weighted, 20 Hz-20 kHz noise bandwidth): Analog inputs - Subwoofer channel | 3/5-Channel: > 83 dB |
| Damping factor @ 4 Ω | Monoblock (300 W): > 120/50 Hz Monoblock (600 W): > 1000/50 Hz Monoblock (1000 W): > 1000/50 Hz 2/4/5/6-Channel: > 150/50 Hz 3-Channel: > 120/50 Hz |
| Damping factor @ 2 Ω | Monoblock (300 W): > 60/50 Hz Monoblock (600 W): > 500/50 Hz Monoblock (1000 W): > 500/50 Hz 2/4/5/6-Channel: > 75/50 Hz 3-Channel: > 60/50 Hz |
| THD+N @ rated power | Monoblock (300 W/600 W)/2/4/6-Channel: <1% @ 2 Ω per Channel |
| THD+N @ rated power: Main channels | 3/5-Channel (700 W/1000 W): <1% @ 2 Ω per Channel |
| THD+N @ rated power: Subwoofer channel | 3/5-Channel (700 W/1000 W): <1% @ 2 Ω per Channel |
| Frequency response (+0, -1dB) | Monoblock (300 W): 10 Hz-1 kHz Monoblock (600 W/1000 W): 7 Hz-500 Hz 2/4/6-Channel: 12 Hz-22 kHz |
| Frequency response (+0, -1dB): Main channels | 3/5-Channel (700 W/1000 W): 12 Hz-22 kHz |
| Frequency response (+0, -1dB): Subwoofer channel | 3/5-Channel (700 W/1000 W): 10 Hz-1 kHz |
| Input voltage range @ RCA inputs | Monoblock (300 W/600 W/1000 W)/2/3/4-Channel: 200 mV - 4 V RMS |
| Fuse rating | Monoblock (300 W): 30 A Monoblock (600 W): 50 A 2-Channel: 20 A 3-Channel: 50 A 4-Channel: 40 A 5-Channel (700 W): 60 A 6-Channel: 50 A 6-Channel (24 V): 30 A 8-Channel (24 V): 40 A Monoblock (1000 W)/5 (1000 W)/8-Channel: 80 A |
| Recommended fuse type(s) | AFS, AGU or MaxiFuse™ |
| Minimum copper power/ground wire gauge | 2/6 -Channel (24 V): 8 AWG wire Monoblock (300 W/600 W/1000 W)/3/4/5/6/8-Channel (24V): 4 AWG wire |
Signal Processing |
|
| Filter mode(s): Channels 1 & 2 | Monoblock (300 W/600 W/1000 W): Off or Low-Pass only 2/4/6-Channel: Off, Low-Pass or High-Pass 3/5-Channel (700 W/1000 W): Off or High-Pass only |
|---|---|
| Filter slope(s): Channels 1 & 2 | Monoblock (300 W/600 W/1000 W): 12/24 dB/octave 2/3/4/5 (700 W/1000 W)/6-Channel: 12 dB/octave |
| Filter frequency range: Channels 1 & 2 | Monoblock (300 W/600 W/1000 W): 50 Hz-500 Hz 2/3/4/6-Channel: 50 Hz-500 Hz 5-Channel (700 W/1000W): 50 Hz-5 kHz |
| Filter mode(s): Channels 3 & 4 | 4/6-Channel: Off, Low-Pass or High-Pass 5-Channel (700 W/1000 W): Off, High-Pass or Bandpass |
| Filter slope(s): Channels 3 & 4 | 4/5 (700 W)/6-Channel: 12 dB/octave |
| Filter frequency range: Channels 3 & 4 | 4/5 (700 W)/6-Channel: 50 Hz-500 Hz |
| Filter mode(s): Channels 5 & 6 | 6-Channel: Off, Low-Pass or High-Pass |
| Filter slope(s): Channels 5 & 6 | 6-Channel: 12 dB/octave |
| Filter frequency range: Channels 5 & 6 | 6-Channel: 50 Hz-500 Hz |
| Filter mode(s): Subwoofer channel | 3/5-Channel (700 W/1000 W): Off or Low-Pass only |
| Filter slope(s): Subwoofer channel | 3/5-Channel (700 W/1000 W): 12/24 dB/octave |
| Filter frequency range: Subwoofer channel | 3/5-Channel (700 W/1000 W): 50 Hz-500 Hz |
| Detented, calibrated filter frequent potentiometers | |
| Infrasonic filter: Subwoofer channel | Monoblock (600 W): 30 Hz, defeatable |
| Remote level control | Optional HD-RLC or MHD-RLC (water-resistant) |
| Remote level modes | 3/5-Channel (700 W/1000 W): All Channels or Sub Channels |
| Channel input mode switch | 3/4-Channel: yes (2/4 Channels) 5-Channel (700 W/1000 W): yes (2/4/6 Channels) |
| Pass-through preamp output | Monoblock (300 W/600 W)/2/3/4-Channel: Buffered |
| Source channel selection for PreOuts | 3/5-Channel (700 W/1000 W): yes (1&2/Sum/Sub) 4-Channel: yes (1&2/Sum) |
