JL Audio® VXi Car System Amplifier with Integrated DSP/ 5 Channel (700W) (VX700/5i)

JL Audio • Amplifiers

$1,449.99

Free Shipping on Orders Above $199
Add to Cart to See Additional Discounts!

Price Matching

Fast Shipping

Live Support

Deep Discounts

PART NUMBER: 010-03332-00

REFERENCE-GRADE AMPLIFIERS WITH DIGITAL SIGNAL PROCESSING (DSP) TECHNOLOGY

Offering exceptional tuning power and flexibility, VXi amplifiers combine our second-generation NexD2^™ high-speed switching technology with a powerful DSP, all within a compact, beautiful package.

COMPREHENSIVE ONBOARD TUNING FOR EXCEPTIONAL SOUND QUALITY

REMOVABLE POWER, SIGNAL AND SPEAKER CONNECTORS

12-VOLT REMOTE WIRE, SIGNAL SENSING OR DC OFFSET TURN-ON OPTIONS

UP TO 6 REMOTE-CONTROLLED STORABLE PRESETS (REMOTE SOLD SEPARATELY)

FULLY CONFIGURABLE ANALOG OR OPTICAL OUTPOUT CHANNEL

2-YEAR WARRANTY

General
Warranty	2 years
Channels	5
Physical dimensions (Height)	2.12" (54 mm)
Physical dimensions (Width)	5-Channel (700 W): 9.81" (250 mm) 5-Channel (1000 W): 11.32" (287 mm)
Physical dimensions (Depth)	6.62" (168 mm)
Weight	5-Channel (700 W): 5.6 lbs (2.54 kg)
Operating voltage	11-14.5 VDC

Audio
Amplifier class	Class D
Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD)	5-Channel (700 W): Main: 75 W x 4/Sub: 180 W x 1 5-Channel (1000 W): Main: 75 W x 4/Sub: 400 W x 1
Rated continuous (RMS) power (14.4 V input @ 2 Ohm < 1% THD)	5-Channel (700 W): Main: 100 W x 4/Sub: 300 W x 1 5-Channel (1000 W): Main: 100 W x 4/Sub: 600 W x 1
Rated continuous (RMS) power (12.5 V input @ 4 Ohm < 1% THD)	5-Channel (700 W): Main: 60 W x 4/Sub: 180 W x 1 5-Channel (1000 W): Main: 60 W x 4/Sub: 360 W x 1
Rated continuous (RMS) power (12.5 V input @ 2 Ohm < 1% THD)	5-Channel (700 W): Main: 90 W x 4/Sub: 300 W x 1 5-Channel (1000 W): Main: 90 W x 4/Sub: 600 W x 1
Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Main Channels	99 dB
Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Subwoofer Channel	99 dB
Signal-to-Noise Ratio, referred to highest rated power: Digital Inputs - Main Channels	101 dB
Signal-to-Noise Ratio, referred to highest rated power: Digital Inputs - Subwoofer Channel	102 dB
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Main Channels	80 dB
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs - Subwoofer Channel	72 dB
Signal-to-Noise Ratio, referred to 1 W: Digital Inputs - Main Channels	82 dB
productSpecSN1wDigitalInputsSubw	80 dB
Damping factor @ 4 Ω	>150/50 Hz
Damping factor @ 2 Ω	>50/50 Hz
THD+N @ Rated Power: Main Channels	<1% @ 2 Ω
THD+N @ Rated Power: Subwoofer Channel	<1% @ 2 Ω
Frequency response (+0, -1dB): Main Channels	12 Hz-21 kHz
Frequency response (+0, -1dB): Subwoofer Channel	12 Hz-1 kHz
Input voltage range @ RCA inputs	200 mV-16 V RMS
Fuse rating	5-Channel (700 W): 60 A 5-Channel (1000 W): 80 A
Recommended fuse type(s)	AFS, AGU or MaxiFuse™
Min. copper power/Ground wire gauge	4 AWG wire
