JL Audio RD Car Full-range Amplifier/ 6 Channel (800W)

JL Audio • Amplifiers

$649.99

Free Shipping on Orders Above $199
Add to Cart to See Additional Discounts!

Price Matching

Fast Shipping

Live Support

Deep Discounts

SLEEK, POWERFUL, PACKED WITH VALUE

The look is amazing, and the performance backs it up. These ultracompact full-range RD series amplifiers from JL Audio are engineered to generate loads of power with exceptional efficiency and low distortion. The result: premium audio quality with significantly reduced current draw and heat.

12-DECIBEL/OCTAVE FILTER WITH VARIABLE HIGH-, LOW- AND BAND-PASS FILTERS

SELECTABLE INPUT VOLTAGE: LOW (200 mV TO 2-VOLT RMS) TO HIGH (800 mV to 8-VOLT RMS)

3 TURN-ON OPTIONS: +12-VOLT REMOTE WIRE, SIGNAL SENSING OR DC OFFSET

ONBOARD LED CLIPPING INDICATOR SIMPLIFIES LEVEL SETTING

SIGNAL ROUTING FLEXIBILITY WITH SELECTABLE INPUT MODE AND TYPE

2-YEAR WARRANTY

General
Warranty	2 years
Channels	4/6
Physical dimensions (Height)	2.13" (54 mm)
Physical dimensions (Width)	4-Channel: 9.78" (248 mm) 6-Channel: 14.66" (372 mm)
Physical dimensions (Depth)	6.96" (177 mm)
Weight	4-channel: 6.35 lbs (2.88 kg) 6-channel: 7.15 lbs (3.6 kg)
Operating voltage	10-15 VDC
Operating temperature range	–4º to 149º F (–20º to 65º C)

Audio
Amplifier class	Class D
Rated continuous (RMS) power (14.4 V input @ 4 Ohm < 1% THD)	4-Channel: 75 W x 4/200 x 2 (Bridged) 6-Channel: 75 W x 4/150 x 2 200 W x 2/400 W x 1 (Bridged)
Rated continuous (RMS) power (14.4 V input @ 2 Ohm < 1% THD)	4-Channel: 100 W x 4 6-Channel: 100 W x 4/200 x 2
Rated continuous (RMS) power (12.5 V input @ 4 Ohm < 1% THD)	4-Channel: 60 W x 4/180 x 2 (Bridged)
Rated continuous (RMS) power (12.5 V input @ 2 Ohm < 1% THD)	4-Channel: 90 W x 4
Signal-to-Noise Ratio, referred to highest rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs	>104 dB
Signal-to-Noise Ratio, referred to 1 W (A-weighted, 20 Hz - 20 kHz noise bandwidth): Analog Inputs	>84 dB
Damping factor @ 4 Ω	>150/50 Hz
Damping factor @ 2 Ω	>75/50 Hz
THD+N @ Rated Power	<1% @ 4 Ω
Frequency response (+0, -1dB)	12 Hz-22 kHz
Input voltage range @ RCA inputs	Switchable from 200 mV-2 V RMS (Low) to 800 mV-8 V RMS (High)
Input impedance	10 kΩ (Low) 2.7 kΩ (High)
Current consumption (Idle)	1,900 mA-2,000 mA
Fuse rating	4-Channel: 40 A 6-Channel: 80 A
Recommended fuse type(s)	AFS, AGU or MaxiFuse™
Min. copper power/Ground wire gauge	4 AWG wire
Protection circuits	Over temperature, Ground short, Speaker overcurrent

Signal Processing
Filter mode(s): Channels 1 & 2	4-Channel: Off, Low-pass or High-pass 6-Channel: High-pass only (Off, x1, x10)
Filter Slope(s): Channels 1 & 2	12 dB/octave
Filter frequency range: Channels 1 & 2	4-Channel: 50 Hz-500 Hz 6-Channel: 50 Hz-500 Hz (x10: 500 Hz-5 kHz)
Filter mode(s): Channels 3 & 4	4-Channel: Off, Low-pass or High-pass 6-Channel: Off, High-pass or Bandpass
Filter Slope(s): Channels 3 & 4	12 dB/octave
Filter frequency range: Channels 3 & 4	50 Hz-500 Hz
Filter mode(s): Channels 5 & 6	6-Channel: Off, High-pass or Bandpass
Filter Slope(s): Channels 5 & 6	6-Channel: 12 dB/octave
Filter frequency range: Channels 5 & 6	6-Channel: 50 Hz-500 Hz
Detented, calibrated filter frequent potentiometers	yes
Channel input mode switch	4-Channel: yes (2/4 Channels) 6-Channel: yes (2/4/6 Channels)
Pass-through preamp output	Buffered
